Fire Retardant EVA Foam

Density : 30 ±5 kg /m 3
Color : Black, White, Green, Blue and customized




Thickness: 1mm to 100mm ( block size ), laminated max 200mm

Sheet Size : 100mm x 1250mm x 2050mm

                       80 mm x 1250mm x 2050mm

                       100mm  x 1050mm x 2050mm

                       100mm x 2450mm x 1250mm

                       60mm    x 2050mm x 1050mm

                       50mm   x  1500mm x 4000mm

                       Customized Size available !

Color        :   Black, White, Grey or customized

Shore hardness  :     20 shore C to 80 shore C

Special  Foam : Fire Retardant, Anti- Static, Surface texture etc.

Function: Thermal insulation, Waterproof and Sound insulation

Application: HVAC& Air conditioner, Automotive, Building and Construction, Sports & Leisure etc.

Certificate: SGS CE Reach UL etc.




DESCRIPTIONS - Fire Retardant EVA Foam

EVA foam, or Ethylene Vinyl Acetate foam, is a versatile, closed-cell material known for its flexibility, resilience, and durability. It offers excellent cushioning, shock absorption, and water resistance. Lightweight and easy to work with, EVA foam is used in various applications, including footwear, sports equipment, toys, and packaging. Its fine cell structure and smooth surface make it suitable for precise and aesthetic uses.

FEATURES - Fire Retardant EVA Foam

● FINE AND UNIFORM CELL STRUCTURE
● EXCELLENT THERMAL INSULATION
● SUPERIOR CUSHIONING
● SOUND ABSORPTION
● LIGHTWEIGHT
● CHEMICAL RESISTANCE
●SMOOTH SURFACE

SPECIFICATION - Fire Retardant EVA Foam

TECHNICAL DATA SHEET OF EVA FOAM SHEET
TEST ITEM SPEC.
DENSITY（kg/m3） 20±5 25±5 35±5 40±5 50±5 60±5 80±10 100±15 150±20 200±30

Shore C

Hardness (°)

 15-20 18-20 20-25 25-30 30-35 30-35 35-40 40-45 50-60 65-75

Tensile Strength

(Mpa)

 ≥0.12 ≥0.15 ≥0.2 ≥0.2 ≥0.3 ≥0.3 ≥0.4 ≥0.5 ≥1.1 ≥1.2

Elongation(%)

 ≥100 ≥100 ≥100 ≥110 ≥120 ≥130 ≥160 ≥180 ≥190 ≥200

Tearing Strength(KN/m)

 ≥1.1 ≥1.1 ≥1.1 ≥1.1 ≥1.5 ≥2.0 ≥2.5 ≥2.5 ≥3.0 ≥3.0

Compressed Distortions

23℃±2℃, 22h

 ≤11 ≤11 ≤10 ≤10 ≤9 ≤8 ≤8 ≤8 ≤7 ≤7

Size Changed

（%）

70℃±2℃, 24h

 ≤ -6 ≤ -6 ≤ -6 ≤ -6 ≤ -5 ≤ -5 ≤ -5 ≤ -5 ≤ -4 ≤ -4

Water Absorption(%)

23℃±2℃, 24h

 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8 ≤ 8

Thermal Conductivity（w/m.k）

 ≤ 0.040  ≤ 0.040 ≤ 0.045 ≤ 0.055 ≤ 0.055 ≤ 0.055 ≤ 0.065 ≤ 0.065 ≤ 0.065 ≤ 0.075
THE ABOVE DATA IS FOR REFERENCE ONLY. ACTUAL PRODUCT DATA SHALL PREVAIL !

PROPERTIES - Fire Retardant EVA Foam

  Weather Rsistance

Excellent resistance to ozone, UV rays, and extreme weather conditions.


Flexibility and Cushioning


Offers excellent cushioning and conforms to irregular surfaces, providing effective sealing and shock absorption.


Durability


Resists UV rays, ozone, and aging, ensuring long-term performance even in outdoor environments.


Sound Dampening


Reduces noise and vibration, perfect for automotive, industrial, and construction applications.
Temperature Resistance

Performs well in a wide temperature range, from -40°C to +120°C.


Chemical Resistance


Withstands exposure to diluted acids and alkalis, suitable for harsh environments.


Cost-Effective


Provides high value due to its versatility and long service life.


Thermal Insulation


Provides superior thermal insulation, reducing heat transfer.

APPLICATION - Fire Retardant EVA Foam

RELATED PRODUCTS

Foam expansion joint filler sealing tapes
PE FOAM TAPES
NBR Foam tube production line
NBR FOAM TUBES
eva foam puzzle mats
EVA FOAM PUZZLE MATS
NBR PVC BLEND INSULATION FOAM
CLOSED CELL NBR FOAM
IXPE FOAM ROLLS
30KG IXPE FOAM ROLLS
open-cell-epdm-foam-90kg-2
90KG OPEN CELL EPDM FOAM

FAQ for Fire Retardant EVA Foam

  • Q What's the processing capacity we have ?

    A 1. Cutting - cutting the size as per client’s request
    2. Slicing - Slicing the thickness as per client’s request
    3. Lamination - hot melt film lamination, flame lamination, and pressure-sensitive adhesive lamination
    4. Laser Vibrator - New type cutting machine, can cut the foam drawing without open molds
    5. Die cutting - Open molds as per your design then at first, use die cutting machine to produce, it’s quicker than laser vibrator.
    6. Compression Molding - Compression molding is a process we utilizes for the manufacturing of three-dimensional molded foam and foam composite parts. It is an ideal process for making parts that have intricate features, require very defined part geometry, have varying wall thicknesses or need to be held to critical dimensional tolerances.
    7. Engraving machine - Usually to make tool box insert and packing insert as per client’s requests.
    8. Silk-screen printing - Print logos and patterns on the surface of foam products
    9. Adhesive backing - Gluing on the surface of the foam with liners. Usually produce foam tapes and other products need to stick on.

  • Q How to get samples ?

    A Send enquiry to sales@aitofoam.com, with your details of the foams need, we will check reply in 24 hours.

  • Q What’s your MOQ of Foam Products ?

    A Aito Foam has regular stocks of normal products in our product list. But we have MOQ request of customized foam products, like Special spec. ( length, width, thickness) of rough buns(untrimmed sides and with skins), Customized colors, Density and Hardness.
    More details pls contact us : sales@aitofoam.com

  • Q What’s the kinds of Foam Products you can provide ?

    A Aito Foam is your one stop foam products supplier. We can provide EVA foam, XLPE foam, CR foam, Neoprene, NBR foam and EPDM foam.
    Pls feel free to send us enquiries.sales@aitofoam.com

  • Q What’s the max thickness you can produce ?

    A Aito Foam can laminated different thickness layers into one sheet, our max thickness of lamination is 200mm.
    If you need to buy super thicker foam sheet pls contact us freely. sales@aitofoam.com

  • Q How many color of foam products you can produce ?

    A Aito Foam can produce special colors as per PANTONE CODES! send your pantone codes or sample color to us we will produce sampel accordingly!

  • Q What kinds of foam materials we can supply ?

    A

    Aito Foam can supply :EVA foam, PE foam, XPE foam, IXPE foam, CR foam, EPDM foam, Neoprene foam, SBR foam, NBR foam, Micro-cell soft PVC foam.
    All of them we can supply in sheet and roll.

  • Q Who we are ?

    A

    Aito Foam is a leading foam production and processing factory, we can provide a variety of foam products, such as EVA foam, PE foam, neoprene foam, EPDM foam and NBR foam.

    At the same time, we have advanced processing capabilities to convert foam into the products you need.
